Screw diameter: Ф20-Ф220
Mould clamping force: 100KN-35000KN
Shot weight:30-30000G
Screw can be mated with different heads of screw.
Cyclinder can be mated with differernt sprinkler heads.
Technical Parameter:
Hardness After Hardening & Tempering:HB280-320
Nitrided hardness: 950-1100HV
Nitrided layer depth:0.50-0.80mm
Nitrided brittleness: ≤2 level
Surface roughness: Ra 0.4μm
Linearity of screw: 0.015mm/m
Bimetallic layer depth: ≥3mm
Bimetallic hardness: HRC60-72
Hard-chrome plating hardness after nitriding: ≥950HV
Chrome-plating layer depth: 0.025~0.10mm
Product classification:
According to different ingredents and products the screw can be chosen: general type, pin type, barrier type, separation type, and gas-exhausting/vented type, etc.
Technical Parameter:
|
Shot Weight(g) |
Screw Dia.×L(mm) |
Barrel OD ×L(mm) |
Shot Weight(g) |
Screw Dia.× L(mm) |
Barrel OD ×L(mm) |
|
30-90 |
Φ30x90 |
Φ85x860 |
800-1250 |
Φ75x1825 |
Φ170x1725 |
|
60-125 |
Φ35x910 |
Φ85x860 |
1000-1500 |
Φ80x2000 |
Φ180x1805 |
|
100-150 |
Φ38x935 |
Φ95x900 |
1250-2000 |
Φ85x2300 |
Φ190x1900 |
|
125-160 |
Φ40x980 |
Φ95x910 |
2000-3000 |
Φ90x2700 |
Φ210x2000 |
|
125-300 |
Φ42x1030 |
Φ105x8880 |
2500-5000 |
Φ100x2600 |
Φ230x2405 |
|
250-400 |
Φ45x1210 |
Φ115x1165 |
3000-6000 |
Φ110x2600 |
Φ256x2590 |
|
300-500 |
Φ50x1300 |
Φ125x1260 |
4000-10000 |
Φ120x2800 |
Φ256x2800 |
|
450-600 |
Φ55x1335 |
Φ130x1320 |
6000-8000 |
Φ130x3010 |
Φ256x2970 |
|
500-700 |
Φ56x1350 |
Φ130x1350 |
8000-10000 |
Φ145x3010 |
Φ256x3200 |
|
500-700 |
Φ60x1380 |
Φ140x1350 |
10000-15000 |
Φ160x3500 |
Φ270x3200 |
|
650-800 |
Φ65x1415 |
Φ150x1420 |
13000-25000 |
Φ170x3415 |
Φ317x3380 |
|
700-1000 |
Φ70x1790 |
Φ160x1685 |
|
|
|
 |
|
 |
 |
 |
 |
